Volkswagen Tiguan Charging cable

The Volkswagen Tiguan eHybrid is a plug-in hybrid compact SUV spanning two generations of Volkswagen's modular MQB platform. The second-generation Tiguan (Mk2, 2021–2023) used a 1.4 TSI engine paired with a front electric motor for 245 hp combined, a 13 kWh battery with 10.4 kWh usable, and a WLTP electric range of around 46 km (29 miles). The third-generation Tiguan (Mk3, 2024–present) introduces a significantly upgraded system: a 1.5 TSI evo2 engine with a more powerful electric motor, available in two outputs — 150 kW (204 hp) and 200 kW (272 hp) — both using a 25.7 kWh battery with 19.7 kWh usable and delivering a WLTP electric range of 112–129 km (70–80 miles). Both generations carry the charging port on the left front wing.

The Mk2 eHybrid uses a 3.6 kW single-phase onboard AC charger and has no DC charging capability. The Mk3 eHybrid introduces an 11 kW three-phase onboard AC charger alongside DC charging at up to 50 kW via CCS2, enabling a 10–80% charge in approximately 30 minutes. The battery in the Mk3 is located ahead of the rear axle, preserving luggage space.

Wallbox charging

On the Mk2, the 3.6 kW charger fills the 10.4 kWh usable battery from empty in approximately 3 hours 10 minutes at any wallbox or public AC charge point. On the Mk3, the 11 kW three-phase charger fills the 19.7 kWh usable battery in approximately 2 hours from a three-phase wallbox. On a single-phase supply, the Mk3 charger draws one phase at 3.7 kW, extending a full charge to around 5 hours 50 minutes. A three-phase wallbox makes full use of the Mk3's onboard charger.

Choosing the right cable

An 11 kW Voldt® Type 2 cable is the correct match for both generations of the Tiguan eHybrid. On the Mk2, it handles the 3.6 kW single-phase charger without restriction. On the Mk3, it matches the standard 11 kW three-phase charger exactly. A 22 kW cable is equally well suited to both and adds forward compatibility for any future vehicle with a higher-rated onboard charger.

Cable length

Voldt® Type 2 cables are available in lengths from 4 m up to 40 m. Because the charging port is on the left front wing, the Tiguan generally parks nose-first towards the wallbox for the most direct cable run. A 6 m cable suits most home wallbox setups where that orientation is straightforward. An 8 m or 10 m cable gives more flexibility for driveways and garages where the car cannot always park squarely in front of the charge point. For public charge points and workplace bays where the charger position varies, lengths from 10 m upward remove any concern about reach, and Voldt® supplies cables up to 40 m for installations where a longer run is genuinely needed.

Portable charging with a CEE charger

Both generations of the Tiguan eHybrid have compact enough batteries to charge fully in a reasonable time from industrial CEE sockets, making the Voldt® portable EV charger a practical option at campsites, workplaces, and event venues. On the Mk2, the single-phase 3.6 kW charger draws at its ceiling from any CEE socket type, giving a full charge in approximately 3 hours 10 minutes regardless of socket phase count. On the Mk3, a 32A or 16A three-phase CEE socket delivers the full 11 kW, giving a full charge in approximately 2 hours; at a 16A single-phase CEE socket, the charger draws one phase at 3.7 kW, extending a full charge to around 5 hours 50 minutes. The 32A three-phase portable charger reaches the Mk3's full 11 kW ceiling and covers any other vehicles in a mixed household or fleet at their respective ceilings.

Voldt® charging cables are CE, UKCA and TÜV certified and manufactured according to IATF 16949 automotive quality standards. Single-piece moulded connectors, no glue or screws. IP67-rated for operation between −30°C and +50°C. 100% copper conductors with silver-plated contacts. Tested beyond 10,000 connection cycles. Three-year warranty, 100-day returns, free shipping across Europe.
